Tenways AGO X

Tenways AGO X
  • Color: Ocean Blue
  • Color: Midnight Black
  • Color: Starlight Silver
$2,199.00
Color:
Size: Select size
Wheel Size: 29-inch
Please select options Unavailable
Order now and pick up in-store for free

Details

The Urban All-rounder

Designed Around You
A beast on weekends, and a plow horse on weekdays. The AGO X offers enhanced safety and comfort, no matter if you are planning for commuting, or off-road adventure.

SR SUNTOUR Lockout Fork
- A guaranteed smooth ride wherever your journey takes you, be it flat or bumpy roads.

80 Nm Mid-Drive Motor
- Integrated with an industry-leading torque sensor, this mid-drive motor is built for conquering hills or slopes with ease.

Shimano 10-speed Drivetrain
- Enhanced climbing ability thanks to a wide range of gear ratios. Crisp, satisfying shifting.

Integrated Front & Rear Lights
- Cycle with confidence day and night with fully integrated front and rear lights that illuminate your route and improve your visibility.

29" Puncture-resistant Tires
- Enjoy fewer maintenance stops, thanks to puncture-resistant tires with diamond-design treads for enhanced traction and safety.

Hydraulic Disc Brakes
- All-weather stopping power with durable and reliable braking.

Selle Royal Saddle
- Relax with an ergonomic design created to relieve pressure from long-distance riding.

Integrated Torque Sensor
- Integrated with the mid-drive motor, offering the most natural and comfortable pedaling sensation.

Ride Smart.
Ride Connected.
- Connect with the TENWAYS App to record your rides in real time and track your stats.
- Cast directions straight to the integrated LCD display for seamless navigation.
- Communicate with our team directly through the integrated help center.

Geometry

Sizes:
SIZE (mm)SYMBOLMLXL
Effective top tube A 610 625 640
Seat tube length B 470 500 530
Head tube C 145 160 170
Steering angle D 68.5 70 70
Seat tube angle E 74 73 73
Chainstay F 460 460 460
Wheelbase G 1161 1146.3 1161.9
Standover H 839 847 869


- Size: For riders  5'3" - 5'9"

This electric bicycle may exceed certain speed or power limits defined for e-bikes depending on local or state regulations. It is the rider’s responsibility to ensure compliance with all applicable laws and use restrictions before operating this bicycle.

Specs

Frame 6061 Aluminum Frame
Fork SR SUNTOUR Lockout Fork
Wheels 6061 Aluminum Rims
Tires CST Puncture-proof 29" x 2.25" Tires
Bottom Bracket Bottom Bracket Integrated with the Bafang M410 Mid-drive Motor
Crankset Aluminum Alloy Crankset
Cassette/Freewheel Shimano 10-speed Drivetrain
Brakes Hydraulic Disc Brakes
Motor Bafang M410 Mid-drive Motor (250W Power, 80 Nm Torque)
Battery 36V, 14Ah Lithium-ion Battery with LG Cells
Controller/Display Integrated Controller of the Mid-drive Motor/TFT LCD Color Display

* Subject to change without notice.

Part Numbers

Option MPN
Ocean Blue / Medium / 29-inch TEBA52470004
Ocean Blue / Large / 29-inch TEBA52500004
Ocean Blue / X-Large / 29-inch TEBA52530004
Midnight Black / Medium / 29-inch TEBA52470003
Midnight Black / Large / 29-inch TEBA52500003
Midnight Black / X-Large / 29-inch TEBA52530003
Starlight Silver / Medium / 29-inch TEBA52470005
Starlight Silver / Large / 29-inch TEBA52500005
Starlight Silver / X-Large / 29-inch TEBA52530005
